30-Jan-12 The problem of waiting so long to finish this section: with the pilot truck assembled and installed, there is no way for me to get my fingers under the frame to loosen the bolts the bracket will mount to. I end up removing the pilot truck pivot bolts, sliding the bracket down but not removing the truck because all the suspension is still connected.
